美國American Power Design(APD)高壓電源模塊DCDC轉換器

發布時間：2025-05-06 09:43:29 瀏覽：705

　　美國電源設計公司(American Power Design, Inc.)是一家專注于高壓直流/直流轉換器(High Voltage DC/DC Converters)的制造商，其產品廣泛應用于需要高電壓輸出的電子設備和系統中。這些轉換器以其高性能、高可靠性和靈活的輸入輸出電壓范圍而受到市場的青睞。

American Power Design高壓DC/DC轉換器產品介紹

　　應用領域

　　American Power Design 的高壓直流/直流轉換器廣泛應用于以下領域：

　　工業設備：用于高電壓驅動設備、工業自動化系統等。

　　科研儀器：適用于實驗室設備、高精度儀器等需要高電壓輸出的場景。

　　醫療設備：用于需要高電壓電源的醫療成像設備等。

　　航空航天：為航空航天設備提供高可靠性、高電壓的電源解決方案。

　　產品系列

系列	輸出功率	輸出電壓	輸入電壓范圍
A5	5.0 W	24Vdc to 200Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
A15	15.0 W	24Vdc to 200Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
A50	50.0 W	24Vdc to 200Vdc	10-20Vdc, 18-36Vdc, 36-72Vdc
A100	100.0 W	48Vdc to 200Vdc	10-20Vdc, 18-36Vdc, 36-72Vdc
C75	75.0 W	3Vdc to 28Vdc	10-20Vdc, 18-36Vdc, 20-60Vdc, 36-72Vdc
D150	150.0 W	3Vdc to 28Vdc	10-20Vdc, 18-36Vdc, 20-60Vdc, 36-72Vdc
E1	1.0 W	-8000Vdc to 8000Vdc	11.5V-16Vdc
E3	3.0 W	-8000Vdc to 8000Vdc	11.5V-16Vdc
F1	1.0 W	-2000Vdc to 2000Vdc	5Vdc, 12Vdc
G10	10.0 W	-20000Vdc to 20000Vdc	22.8V-28.8Vdc
H10	10.0 W	24Vdc to 1000Vdc	5-15Vdc, 9-36Vdc, 20-60Vdc
H30	30.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc
H50	50.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc
H150	150.0 W	24Vdc to 1000Vdc	18-36Vdc, 20-60Vdc
J05	0.5 W	-2000Vdc to 2000Vdc	0V-5Vdc, 0V-12Vdc, 0V-24Vdc
J3	3.0 W	-6000Vdc to 6000Vdc	0V-5Vdc, 0V-12Vdc, 0V-24Vdc
J5	5.0 W	-3000Vdc to 6000Vdc	0V-12Vdc
J10	10.0 W	-3000Vdc to 6000Vdc	0V-12Vdc , 0V-15Vdc
K10	10.0 W	-4000Vdc to 4000Vdc	0V-12Vdc, 0V-15Vdc, 0V-24Vdc, 0V-28Vdc
L1	1.0 W	24Vdc to 500Vdc	5Vdc, 12Vdc, 24Vdc, 48Vdc
L3	3.0 W	24Vdc to 500Vdc	5Vdc, 12Vdc, 24Vdc, 48Vdc
M5	5.0 W	24Vdc to 1000Vdc	10-20Vdc, 18-36Vdc
M10	10.0 W	24Vdc to 1000Vdc	10-20Vdc, 18-36Vdc
M30	30.0 W	48Vdc to 1000Vdc	10-20Vdc, 18-36Vdc
P1	1.0 W	-3000Vdc to 6000Vdc	0-12Vdc
P2	2.0 W	-3000Vdc to 6000Vdc	0-12Vdc
P3	3.0 W	-3000Vdc to 12000Vdc	0-12Vdc, 0-15Vdc
P10	10.0 W	100Vdc to 8000Vdc	4-12Vdc
Q2	2.0 W	-5000Vdc to 5000Vdc	24V-30Vdc
Q4	4.0 W	-5000Vdc to 5000Vdc	24V-30Vdc
S1	1.0 W	50Vdc to 500Vdc	9-36Vdc
S3	3.0 W	50Vdc to 500Vdc	9-36Vdc
S5	5.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
S10	10.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
S20	20.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
S30	30.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
X10	10.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
X30	30.0 W	24Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
X50	50.0 W	48Vdc to 1000Vdc	9-36Vdc, 20-60Vdc, 36-72Vdc
X150	150.0 W	48Vdc to 1000Vdc	18-36Vdc, 20-60Vdc, 36-72Vdc

深圳市立維創展科技有限公司優勢代理銷售American Power Design(APD)高壓DC/DC轉換器產品，歡迎咨詢了解。
