650V H6.5三電平功率模塊10-FY07BVA075S5-LF45E18
發布于：2025-11-24 13:48:52
品牌名稱：Vincotech
重要參數：
電壓：650V
電流：30A - 100A
高度：12mm
| Part-no details / Part-no datasheet | Sub-Topology | Product line | Voltage | Current | Main Chip technology | Housing family | Height | Isolation |
| in V | in A | in mm |
| 10-FY07BVA075S5-LF45E18 | Dual Booster+H6.5-KE-NTC | flowSOL 1 BI (TL) | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA075S502-L985F18Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA075RG-L985F88Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100S521-L986F33 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100S521-L986F33Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FZ07BVA030S5-LD45E08 | Booster + H6.5-KE-NTC | flowSOL 0 BI (TL) | 650 | 30 | IGBT S5 | flow 0 | 12 | Al2O3 |
| 10-FY07BVA050S5-LF44E18 | Dual Booster+H6.5-KE-NTC | flowSOL 1 BI (TL) | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100RG-L986F88 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-PY07BVA050S5-LF44E18Y | Dual Booster+H6.5-KE-NTC | flowSOL 1 BI (TL) | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07BVA075S5-LF45E18Y | Dual Booster+H6.5-KE-NTC | flowSOL 1 BI (TL) | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100RG11-L986F58 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100RG11-L986F58Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100RG01-L986F48 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100RG01-L986F48Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA050RG01-L984F48 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-PY07HVA050RG01-L984F48Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA075S5-L985F08 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA050S5-L984F08Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA050S5-L984F08 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA075S5-L985F08Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100S5-L986F08Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA075RG01-L985F48 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100S5-L986F08 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA075RG01-L985F48Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA075RG-L985F88 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-FY07HVA075S501-L985F28 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100S501-L986F28Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA050RG-L984F88 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT fast | flow 1 | 12 | Al2O3 |
| 10-PY07HVA050S501-L984F28Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA050S501-L984F28 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 50 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA075S501-L985F28Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100S511-L986F38 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-PY07HVA100S511-L986F38Y | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100S501-L986F28 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA100S502-L986F18 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 100 | IGBT S5 | flow 1 | 12 | Al2O3 |
| 10-FY07HVA075S502-L985F18 | H6.5-KE-NTC | flowPACK 1 H6.5 | 650 | 75 | IGBT S5 | flow 1 | 12 | Al2O3 |
